Alpine Head Unit iLX-702D

Alpine Head Unit iLX-702D


The iLX-702D Digital Media Station brings the latest media compatibility, online navigation capability and Alpine’s audiophile sound quality to your ride. It is fully compatible with the latest smartphones such as the iPhone 7 and the Galaxy S7 and lets you use Android Auto and Apple CarPlay on its 7-inch high-resolution touch screen.

DAB+ digital radio, USB video playback, HDMI connectivity and the latest Bluetooth technology are built-in as well.

You even have several options for navigation: the iLX-702D includes online navigation capability to use Maps with Apple CarPlay and Google navigation with Android Auto. Both Apple CarPlay and Android Auto apps can access the Alpine navigation antenna for highest positioning accuracy.



  •     Memory Presets: Preset Stations (FM: 24 / MW: 6 / LW: 6)
  •     Memory: Auto Memory
  •     Seek Mode: Local / DX Selection


  •     RDS Functions: PI, PS, AF, TA, TP, PTY, NEWS, RADIO TEXT

DAB Tuner

  •     DAB+ Tuner Built-in
  •     DAB+/DMB Supported
  •     DAB+ Slideshow Service
  •     DLS (Dynamic Label Service)
  •     DAB Service Following
  •     RDS Fallback (where available)
  •     Service Preset: 18 Preset Memory
  •     Auto Ensemble/Service Memory
  •     Service Search Function
  •     PTY Search Function
  •     Alphabet Search Function
  •     Antenna Power Supply Selection


  •     Built-in BLUETOOTH® Module
  •     Wide Band Speech Technology
  •     HFP (Hands-Free Profile) Compatible
  •     Streaming Music: A2DP (Advanced Audio Distribution Profile) Compatible
  •     Streaming Music Control: AVRCP (Audio / Video Remote Control Profile) Ver.1.5 Compatible
  •     Advanced BLUETOOTH® Technology
  •     Connection: SSP (Simple Secure Pairing) Supported
  •     Individual Profile Connection Hands Free Phone and Music Streaming
  •     Phone Book: Phone Book Synchronization
  •     Speed Dial: 4 Preset Memory (per phone)
  •     Multiple Phone Number Registration: 5 Phone Numbers can be stored for one name
  •     Device Name Display
  •     Auto Answer
  •     Call History Display: Outgoing Calls / Incoming Calls / Missed Calls
  •     Redial Function
  •     Speech Volume Level Adjustment: Possible for Outgoing and Incoming Volume
  •     DTMF (Touch-Tone) Function
  •     Signal Strength Indicator
  •     Battery Level Indicator
  •     Menu Language Selection: 24 Languages
  •     Firmware Updatable
  •     Microphone Included

Made for iPod® / iPhone®

  •     Compatibility for iPod/iPhone: compatible with all models except 1st and 2nd generation iPhone
  •     Connection: KCU-461iV / KCU-471i Required (Sold separately)
  •     Music & Video Playback Compatible with KCU-461iV only
  •     Available Selections: Playlist / Artist / Album /Song / Podcast / Genre / Composer / Audiobook
  •     Alphabet Search
  •     Artwork Display
  •     Direct Up / Down: Playlist / Artist / Album / Genre / Composer
  •     M.I.X. (Shuffle) Play: Song, Albums, All
  •     Repeat
  •     Battery Charging


  •     Works with Apple CarPlay (requires CarPlay enabled iPhone)
  •     Works with Android Auto (Requires Android Auto enabled smartphone)

Navigation Function

  •     Online navigation capability with Apple CarPlay and Android Auto
  •     Includes GPS / Glonass enabled navigation antenna
  •     Direct navigation access key to launch CarPlay or Google maps

USB Media Connection

  •     USB Connection: USB Extension Cable Included
  •     Music Playback: FLAC/MP3/WMA/AAC compatible
  •     Video Playback: MP4 compatible
  •     File / Folder Name Search
  •     Tag Info Search
  •     Folder Up / Down
  •     M.I.X. Random Play
  •     Repeat

Sound Tuning

  •     Bass Engine SQ
  •     Bass Engine™ Pro
  •     Subwoofer Level Adjustment
  •     Subwoofer Phase Select
  •     4V High Voltage PreOut
  •     Equalizer: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, Classical
  •     Dual HD EQ (9-band Parametric Equalizer front/rear)
  •     6 Channel Digital Time Correction
  •     Digital Crossover Setting
  •     Customized Sound Setting by Car Type
  •     MediaXpander HD
  •     Application Volume Level Setting
  •     Sound Setting Data Download
  •     Easy, Step-by-Step Sound Customization
  •     Alpine TuneIt App ready


  •     Power Output: 4 x 50 W High Power Amplifier
  •     Advanced Power IC
  •     Display: 7 inch Capacitive WVGA High Resolution Display
  •     White LED Backlighting System
  •     50/50 Split Screen: Left / Right Position Changeable
  •     Control Type: Touch, Drag, Flick
  •     My Favorites Function
  •     Automatic Setting Change for 2 Users
  •     High Grade Audiophile Design
  •     3 PreOuts (4V, Front / Rear / Subwoofer)
  •     AUX-In: 1 A/V AUX Input (3.5mm micro jack)
  •     Steering Wheel Remote Control Function
  •     Vehicle Display Interface Ready (UART connection)
  •     Remote Control Ready
  •     Navigation Guidance Mix
  •     Camera Connection & Built-in Controls for Multi-View Cameras
  •     Camera Guide Line Adjustment
  •     Rearview Camera Display Automatic Boot-up
  •     Simple Mode & Info Mode Display Selection
  •     Visual EQ
  •     Live Contrast Adjustment
  •     Menu Language: 24 Languages (for AV / Bluetooth)
  •     Clock
  •     Auto Dimmer
  •     Anti-theft security code
  •     Firmware Updatable
  •     Power Antenna Lead
  •     Remote Turn-On
  •     HDMI Input (Alpine Special HDMI connector required)
  •     Engine Start-Stop unaffected
