Hertz DP 4.300 4-Channel Car Amplifier Hi-Res

Hertz DP 4.300 4-Channel Car Amplifier Hi-Res

R3,619.00

Hertz DP 4.300 is a Hi-Res certified 4-channel Class-AB car amplifier delivering 10 Hz to 45 kHz response for precise audio reproduction in a compact bridgeable design.

SKU DP4.300 Category Brand:

The Hertz DP 4.300 is a Hi-Res certified 4-channel Class-AB car amplifier offering a wide 10 Hz to 45 kHz frequency response for accurate high-resolution audio playback.

Despite a compact footprint the unit features fully bridgeable 4-channel Class-AB amplification that is 2 ohm stable, plus an elegant status LED, solid machined terminal block and a removable top panel protecting controls and connections.

Connectivity and controls include balanced Pre-in and Speaker-in inputs, speaker-in sensitivity 1.6 to 40 Vrms, full-range pre-outs, adjustable input levels, 50-4000 Hz 12 dB per octave crossovers, bass boost and Automatic Remote Turn-On that can be driven by OEM radio speaker outputs. The amplifier supports an operating supply voltage range of 6.5 to 16.5 V.

  • Frequency response: 10 Hz – 45 kHz
  • Certification: Hi-Res Audio certified
  • Topology: 4-channel Class-AB, fully bridgeable
  • Stability: 2 ohm stable
  • Operating supply voltage: 6.5 – 16.5 V
  • Speaker-in input sensitivity: 1.6 – 40 Vrms
  • Inputs: Balanced Pre-in and Speaker-in
  • Outputs: Full-range pre-outs available with Pre-in or Speaker-in
  • Crossover: High/low-pass 50 – 4000 Hz 12 dB per octave
  • Controls: Adjustable input levels and bass boost
  • Construction: Solid machined terminal block and removable top panel
  • Hi-Res Audio certification with 10 Hz – 45 kHz frequency response
  • Fully bridgeable 4-channel Class-AB design
  • 2 ohm stable operation
  • Balanced Pre-in and Speaker-in with high-noise rejection
  • Adjustable input levels, 50-4000 Hz 12 dB/Oct crossovers and bass boost
  • Full-range pre-outs available with Pre-in or Speaker-in inputs
  • Automatic Remote Turn-On via OEM radio speaker outputs
  • Solid machined terminal block, removable top panel and status LED
  • Disconnect vehicle battery before installation
  • Use appropriate fusing and wiring gauge for amplifier current draw
  • Ensure adequate ventilation and prevent exposure to moisture
  • Securely mount amplifier to avoid movement and cable strain
  • Observe speaker impedance limits; amplifier is 2 ohm stable
  • Most vehicles with 12 V electrical systems compatible within 6.5 – 16.5 V supply range
  • Works with OEM radios using speaker outputs for Automatic Remote Turn-On
