Kicker KMXL 6×9 Coaxial Speakers Horn-Loaded Tweeter

Kicker KMXL 6×9 Coaxial Speakers Horn-Loaded Tweeter

Proprietary high-frequency horn design delivers smooth, easy-to-listen sonic performance at extreme volumes. 6×9 coaxial speakers sold in pairs with white and charcoal grilles. 1-1/4 inch aluminum tweeters.

Vehicle logos indicate compatibility only. This product is not manufactured or endorsed by the vehicle brand.

The Kicker KMXL 6×9 coaxial speakers use a proprietary high-frequency horn design and 1-1/4 inch aluminum tweeters to provide smooth, controlled sound at high listening levels; sold in pairs. Specifications include 6×9 woofers 160 x 230 mm, 4 ohm impedance, recommended amplifier power 15-150 watts RMS, 300 watts peak power handling, 92 dB sensitivity, 70-20000 Hz frequency response, mounting hole diameter 5-13/16 x 8-9/16 in (148 x 218 mm), mounting depth 3-3/8 in (85 mm), both white and charcoal grilles included, and a 12 dB/octave high-pass crossover at 80 Hz recommended for maximum power handling.
  • Woofer: 6 x 9 in (160 x 230 mm)
  • Tweeter: 1-1/4 in (32 mm) aluminum dome
  • Impedance: 4 ohm
  • Recommended amplifier power: 15-150 watts RMS
  • Peak power handling: 300 watts
  • Sensitivity: 92 dB (1W, 1m)
  • Frequency response: 70-20,000 Hz
  • Mounting hole diameter: 5-13/16 x 8-9/16 in (148 x 218 mm)
  • Mounting depth: 3-3/8 in (85 mm)
  • Grilles: white and charcoal included
  • Crossover recommendation: 12 dB/octave high-pass at 80 Hz
  • Proprietary high-frequency horn design for smooth high-volume performance
  • 1-1/4 in aluminum dome tweeter
  • 6×9 woofer size for common vehicle applications
  • 4 ohm nominal impedance
  • Recommended amplifier power 15-150 watts RMS; 300 watts peak
  • Includes both white and charcoal grilles; sold in pairs
  • 92 dB sensitivity and 70-20 kHz frequency response
  • Disconnect vehicle battery before installation to prevent short circuits
  • Verify polarity and secure wiring connections to avoid damage
  • Confirm mounting depth and hole dimensions to prevent interference with moving parts
  • Avoid exposing speakers to moisture or direct water contact
  • Universal fit for vehicles with 6×9 speaker openings
  • Verify mounting hole dimensions 5-13/16 x 8-9/16 in and depth 3-3/8 in before purchase
