HIGH-POWER MONO SUBWOOFER AMPLIFIER WITH ACCUBASS®

When you demand the perfect blend of power and performance, AudioControl provides answers and the LC-1.1500 is no exception.

No matter the install, you can be assured power will meet and exceed expectations with 1500 watts at 2 ohms. The mix of high level and low level inputs mean you have the widest input voltage range in the industry. AudioControl’s patented AccuBASS® circuit is the only way to properly overcome factory bass roll-off and heavily equalized factory bass settings.

Enjoy loud, clean and articulate bass combined with the best warranty available with the LC-1.1500 amplifier.

Description

FEATURES

  • Subwoofer amplifier with patented AccuBASS®
  • 1500 watts @ 2 ohms
  • 850 watts @ 4 ohms
  • AccuBASS® Processing
  • MILC™ Maximum Input Level Control (Patent Pending)
  • GTO™ Signal Sense
  • 24 dB/octave Linkwitz-Riley Alignment crossover
  • Speaker level and preamp inputs
  • Optional ACR-1 assignable remote control
  • Solid One-Piece Aluminum Chassis

SPECIFICATIONS

INPUTS
Preamp Inputs: 2 balanced
Input Voltage Range: 500 mV – 6 Vrms
Speaker Level Inputs: 2
Speaker Level Input Voltage Range: 3 V – 40 Vrms

OUTPUTS
Rated Continuous (RMS) Power at 14.4V:
4 Ω – 850 W RMS
2 Ω – 1500 W RMS

PERFORMANCE
Frequency Response: 10 Hz – 30 kHz
Signal to Noise: 102 dBa, Ref 850 W @ 4 Ohm
Damping Factor: 670 at 10 V, 4 Ohm Output, 100 Hz
THD+N: < 0.01%
Minimum Power / Ground Wire Gauge: 0 AWG wire
Fuse Rating: 4 x 40 A
Crossover: 24 dB/octave Linkwitz-Riley, Adjustable From 30 Hz – 230 Hz
PFM Subsonic Filter: 24 Hz

WEIGHTS & DIMENSIONS
Dimensions: 12″W x 7.95″D x 2.1″H
Weight: 7.2 lbs (3.3 kg)
