AudioControl ACX-BT1 Bluetooth Streamer IPX5 Marine

AudioControl ACX-BT1 Bluetooth Streamer IPX5 Marine

R1,899.00

The AudioControl ACX-BT1 is an all-weather Bluetooth 4.1 streamer with aptX HD support providing 24-bit 48 kHz audio, IPX5 protection, and a remote amp turn-on for marine and motorsports.

SKU ACX-BT1 Category Brand:

The AudioControl ACX-BT1 is an all-weather Bluetooth 4.1 audio streamer that adds wireless connectivity to systems without a head unit or to existing installs. It supports aptX HD for 24-bit 48 kHz audio and low-latency streaming and provides dual line-level RCA outputs with a nominal output level of 1.5 Vrms.

The IPX5 rated enclosure and built-in fuse make the ACX-BT1 suitable for marine and motorsports applications including side-by-sides and personal watercraft. The unit includes a unique remote turn-on output that triggers downstream amplifiers only when Bluetooth audio is playing.

  • Bluetooth Version: 4.1 with aptX HD support
  • Audio: 24 bit / 48 kHz streaming from aptX devices
  • Outputs: Dual line-level RCA, Nominal Output Level 1.5 Vrms
  • Performance: Signal to Noise Ratio 95 dB; Maximum Data Rate 3 Mbps (typical 1.6 Mbps)
  • Operating Range: 10+ meters depending on environment
  • General: Current Draw 35 mA; Fuse Rating 2 A; Built-in fuse
  • Enclosure Rating: IPX5
  • Dimensions: 2.0″L x 2.5″W x 0.7″H; Weight: 0.2 lbs (91 g)
  • High definition low-latency Bluetooth 4.1 streaming
  • aptX HD support for 24-bit 48 kHz audio
  • Dual line-level RCA outputs
  • IPX5 rated all-weather enclosure
  • Built-in fuse
  • Remote turn-on output that activates only during audio playback
  • Disconnect power before performing installation or wiring
  • Use the specified 2 A fuse rating or equivalent replacement
  • Mount and seal unit to maintain IPX5 protection
  • Route power and signal cables to avoid chafing and water intrusion
  • Consult a professional installer for amplifier turn-on wiring
  • Marine vessels and boats suitable for IPX5 equipment
  • Personal watercraft and jet skis
  • UTVs and side-by-sides
  • ATVs and motorsports vehicles
  • Custom stereo installs without a head unit
