The Phoenix Gold ZLOC2.2 is a 2-input, 2-output active line-output converter that converts high-level speaker signals to low-level RCA outputs up to 7.5 V RMS, bypassing OEM resistance to reduce distortion. It includes gain control, a clip-detection LED, selectable ground isolation (GND/ISO/200 ohm) and REM in/out for streamlined amplifier integration and control in both 12 V and 24 V electrical systems.

The unit features Phoenix Gold Bass CUBE parametric EQ adjustable from 20 Hz to 110 Hz with +/-9 dB adjustment for low-frequency tuning. Input mode selection allows use as a true 2-channel converter or duplicated 2-in/4-out for expanded systems. Professional installation is recommended.
