HELIX AMPLIFY 201 DIRECT Monoblock Subwoofer Amp 750W RMS

HELIX AMPLIFY 201 DIRECT Monoblock Subwoofer Amp 750W RMS

R5,899.00

Compact monoblock subwoofer amplifier designed for DSP systems with DirectDSP input, Class D efficiency, start-stop capability and up to 750W RMS output for precise, powerful bass.

SKU AC20110 Category Tag Brand:

No results found.

The HELIX AMPLIFY 201 DIRECT is a compact monoblock Class D amplifier engineered for subwoofer upgrades and DSP-based car audio systems. It features DirectDSP inputs for direct connection to HELIX DSPs, a high-quality gain stage with clipping LED, and a sealed minimalist design with a removable top cover to protect controls and connections.

The amplifier delivers up to 750 W RMS at 1 Ohm and offers two RCA inputs plus a remote input. It supports start-stop operation down to 6 V for modern vehicles and combines high efficiency with a small footprint for flexible subwoofer installations.

  • Amplifier type: Monoblock Class D
  • Power RMS @ 14.4 V: 1 x 250 W; 1 x 450 W; 1 x 750 W
  • Max output power: Up to 850 W RMS @ 1 Ohm
  • Inputs: 2 x RCA/Cinch, 1 x Remote In
  • Input sensitivity: 0.5 – 8 V
  • Input impedance: 8 kOhms
  • Outputs: 1 x speaker output
  • Frequency response: 10 Hz – 450 Hz
  • Signal-to-noise ratio: 114 dB @ full power
  • Distortion: THD @ 100 Hz < 0.003%; THD+N @ 100 Hz < 0.02%
  • Damping factor: 200
  • Operating voltage: 10.5 – 16 V (max 5 sec down to 6 V)
  • Idle current: 1100 mA
  • Fuse: 2 x 30 A LP-Mini-fuse (APS)
  • Power rating: DC 12 V 80 A max
  • Dimensions (H x W x D): 40 x 248 x 114 mm
  • Additional features: Start-Stop capability, Clipping LED, DirectDSP inputs, removable top cover
  • DirectDSP input optimized for HELIX DSP integration
  • Up to 750 W RMS output at 1 Ohm for subwoofer performance
  • Compact Class D design for high efficiency and low heat
  • Clipping LED and high-quality gain stage for precise level setting
  • Start-stop capable down to 6 V for modern vehicles
  • Removable top cover conceals connections and controls for neat installation
  • Disconnect vehicle battery before installation
  • Use correct gauge power and ground wiring and recommended fuses
  • Mount in a ventilated dry location and avoid contact with exposed metal that could short terminals
  • Do not exceed rated voltage or fuse specifications; observe start-stop limits
  • Professional installation recommended for integration with factory systems and DSP
  • Designed for 12 V automotive electrical systems with negative ground
  • Intended for aftermarket subwoofer installations and DSP-based systems
